DE WIT V70 Series Pneumatic Solenoid Valve - 5/2-Way

DESCRIPTION FOR SOLENOID VALVE SERIES V70 (5/2 WAY)

The Series V70 5/2-Way Directional Solenoid Valve is the gold standard and the most versatile choice for industrial pneumatic automation. Designed for efficient, fast and safe control of double-acting cylinders and actuators, this valve is built to withstand continuous and heavy use, ensuring millions of cycles under the most severe conditions in your plant.

Key Features:

• Heavy-Duty Performance: Features a high-precision machined body that minimizes spool friction and reduces internal seal wear, ensuring extended service life.

• Control Options: Available in single solenoid versions (with automatic spring return when power is cut) or double solenoid (to hold the piston position without continuous electrical power).

• Efficient Centralization: Fully compatible with multiple aluminum bases (BM Series Manifolds), allowing your circuits to be grouped, saving space and wiring and unifying the air exhausts.

• Industrial Protection: Equipped with encapsulated low-consumption coils that prevent overheating and protect the outputs of your control equipment (PLC).

Technical Specifications:

• Function: 5/2 Way (5 ports, 2 positions).

• Actuation Type: Single Solenoid or Double Solenoid.

• Connection Ports: 1/8", 1/4", 3/8" and 1/2" NPT (Body sizes 100, 200, 300 and 400).

• Coil Voltage Options (VT): 12 VDC, 24 VDC, 24 VAC, 110 VAC and 220 VAC.

• Compatible Fluid: Compressed air filtered to 40 microns (lubricated or non-lubricated).

• Working Pressure: 1.5 to 8.0 bar (22 to 115 psi).

• Temperature Range: -5°C to 60°C.

• Protection and Insulation: Coils sealed against dust and water jets with IP65 protection rating and Class F insulation.
